Key Features:

Threaded Connection: Equipped with internal threads that match the external threads of the connecting pipe or fitting, allowing for easy installation without welding.
Ease of Installation: Simple to install and remove, making them ideal for applications where frequent disassembly or maintenance is required.
Material Versatility: Available in a range of materials including carbon steel, stainless steel, alloy steel, and various plastics, suitable for different pressure and temperature conditions.

Common Types:

Standard Threaded Flange: The most common type, featuring internal threads for general applications.
Threaded Flange with Raised Face: Includes a raised face around the bolt holes to enhance the sealing capability, suitable for higher pressure applications.
Threaded Flange with Flat Face: Features a flat surface around the bolt holes, commonly used for lower pressure applications.

Standards and Specifications:

ANSI/ASME B16.5: Standard for pipe flanges and flanged fittings, including threaded flanges, specifying dimensions and tolerances.
ASTM A105: Specification for carbon steel forged fittings for piping applications.
ASTM A182: Standard for alloy and stainless steel pipe flanges, fittings, and valves.
ISO 9001: Quality management system standard ensuring consistent manufacturing and quality control.

Property	Details
Function	Connects pipes, valves, and components using internal threads for a secure, leak-proof connection
Common Types	Standard Threaded Flange, Threaded Flange with Raised Face, Threaded Flange with Flat Face, Threaded Flange with Welded Neck
Materials	Carbon Steel, Stainless Steel, Alloy Steel, Plastic (PVC, CPVC)
Pressure Ratings	Varies by material and design; typically up to 1500 PSI for metal flanges
Temperature Ratings	Depends on material; generally ranges from -50°F to 1500°F for metals
Connection Types	Threaded connection with matching external threads of pipes or fittings
Standards and Specifications	ANSI/ASME B16.5 (Flanges and Fittings), ASTM A105 (Carbon Steel), ASTM A182 (Alloy/SS), ISO 9001 (Quality)
Available Sizes	Typically from 1/2” to 24” diameter or larger
Surface Finishes	Bare, Galvanized, Epoxy Coated, Polyurethane Coated for corrosion protection
Applications	Chemical and Petrochemical, Oil and Gas, HVAC Systems, Water and Wastewater Treatment
Advantages	Easy to install and remove, versatile, cost-effective, leak-proof
